Loading Port:Shenzhen
Payment Terms:L/C,T/T
Min Order Qty:100000 Pcs pc
Supply Capability:100000 Pcs Per Month pc/month
3014 SMD LED Component
1.VF:3.0-3.6V
2.Power:0.1W
3.Brightness:9-10lm/10-11lm
4.ISO9001 factory
3014 SMD LED Component
3014 SMD LED Component Features:
ABSOLUTE MAXIMUM RATING (Ta=25°C)
Item | Symbol | Value | Unit |
Peak Forward Current | IFp | 60 | mA |
Reverse Voltage | VR | 5.0 | V |
Continuous Forward Current | IF | 30 | mA |
Operating Temperature | Topr | -40 to 85 | °C |
Storage Temperature | Tstg | -40 to 100 | °C |
Lead Soldering Temperature | Tsol | 260°C For 3 Seconds | |
CHARACTERISTICS (Ta=25°C)
Parameter | Condition | Symbol | Min | Typ | Max | Units |
Power Dissipation | IF=30mA | Pd | - | 100 | - | mw |
Correlated Color Temperature | IF=20mA | CCT | 5000 | / | 8000 | K |
Forward Voltage | IF=20mA | VF | 2.8 | 3.2 | 3.8 | v |
Reverse Current | VR=5V | IR | / | / | 10 | μA |
Chromaticity Coordinates | IF=20mA | X | / | 0.31 | / | |
Y | / | 0.327 | / | |||
Luminous Flux | IF=20mA | φv | 5 | / | 9 | LM |
Luminous Flux | IF=30mA | φv | 7 | / | 13 | LM |
Color Rending Index | IF =20mA | CRI | / | 70 | / | Ra |
Full Viewing Angle | IF=20mA | 2θ1/2 | / | 120 | / | deg |
REMARK:1:1
Date | 2012-10-19 | Page | 1/1 | Model No. | SD3014WN | CHECKED |
|
REV No. |
A/0 |
Document No. |
1903014001 |
CUSTOMER |
|
APPROVED | Yucheng |
NOTE:
Testing tolerance: VF±0.1V, IV(Φv) ±10%, 2θ1/2±10% ,CCT(λD)±15%;
3014 SMD LED Component Application:
Indoor and outdoor lighting ,outdoor billboard, traffic lighting,car lighting ,LCD backlight portable and mobile lighting as flashlight , emergency lighting,and led dest lamp
