Sc Free Solar Panels 300w 315w Poly Panel for Solar System with All Certificate

Product Description:

300W 315W Poly Panel for Solar System with all Certificate

MANAGEMENT SYSTEM

ISO 9001: Quality management system

ISO 14001: Standard for environmental management system

OHSAS 18001: International standard for occupational health and safety assessment system

Safety

1. salt mist corrosion (IEC61701, tested in Intertek)

2. ammonia corrosion (IEC62716, tested in TÜV SÜD)

3. fire risk (Class C, tested in TÜV SÜD and Rheinland)

Reliability

1. PID free products, passing TÜV SÜD system voltage durability test

2. World 1st company to pass “Thresher Test” and “On-site Power Measurement Validation” certificate

3. Bankable products

Performance

1. Advanced glass and solar cell surface texturing allow for excellent performance in low-light environments

2. 100% In-line Electroluminescence (EL) tested during production process ensures modules are high quality

3. Top rank in Photon yield measurement

Electrical Characteristics

STC: lrradiance 1000 W/m2 module temperature 25OC AM=1.5;

Power measurement tolerance: +/-3%

SRP-300-6PA SRP-305-6PA SRP-310-6PA SRP-315-6PA Unit

Rated Power at STC (Pmp) W

Power Tolerance W

Maximum Power at STC W

Minimum Module Efficiency (ηm) %

Open Circuit Voltage (Voc) V

Short Circuit Current (Isc) A

Maximum Power Voltage (Vmp) V

Maximum Power Current (Imp) A

Maximum System Voltage 1000 (TÜV), 600 (UL) V

Maximum Series Fuse Rating 15 A

Temperature Characteristics

Pmax Temperature Coefficient -0.42 %/°C

Voc Temperature Coefficient -0.32 %/°C

Isc Temperature Coefficient +0.04 %/°C

Operating Temperature -40~+85 °C

Nominal Operating Cell Temperature (NOCT) 45±2 °C

Packing Configuration

Container 20’GP 40’GP 40’HC

Pieces per Pallet 21 21 N.A

Pallets per Container 10 22 N.A

Pieces per Container 210 462 N.A External Dimensions 1956 x 992 x 50 mm

Weight 24 kg

Solar Cells

Front Glass 3.2 mm tempered glass, low iron

Frame Anodized/ Electrophoretic aluminium aloy

Junction Box IP65/IP67

Output Cables 4.0 mm2,symmetrical lengths 900 mm

Connector MC4 Compatible

Mechanical Load 5400 Pa

Hailstone Impact Test 80 km/h for 25 mm ice ball

FAQ about Monocrystalline Solar Panel

1. Q: How do I pay for my purchase order?

     A: T/T, L/C at sight

2. Q: How can I get sample and how long will it takes?

     A: Sample fee will doutbed, but we will return the extra money after you place an order to us, It usually takes 1-3days to produce a sample.

3.  Q: What's the MOQ?

     A: Depend customer's demand.

4. Q: What's the time delivery?

    A: It will take about 5-10 days to finish an order. But the exact time is according to actual situation.

5. Q: Can I have my own customized product?

    A: Yes, your customized requirements for color, logo, design, package,shipping marks etc are available.

6. Q: Do you have quality control?

     A: Yes, we take great control of the quality.

7.  Q:How about the quality?

     A: 10-25 Years.
