Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1000 watt
Supply Capability:1000000 watt/month
260/270/280/290/300w solar panel/pv panel
Features:
1)Long Service Life;
2)High Efficency Solar Cells;
3)Special Aluminum Frame Design;
4)High Transmission,Low Iron Tempered Glass;
5)Advanced Cell Encapsulation.
Solar panel Characteristics
1)High reliability with guaranteed +/-3% output power tolerance.
2)The modules can withstand high wind-pressure,snow loads and extreme temperatures.
3)Bypass diodes to minimize power loss with shading.
4)High and stable conversion efficiency to ensure the highest quality.
Quality and Safety
1)25 Years limited warranty of 80% power output.
2)10 Years limited warranty of 90% output.
3)5 Years limited warranty of materials and workmanshop.
4)ISO9001:2008(Quality management system)certified factory.
5)Product quality warranty & product liability insurance to guarantee and user' benefits.
EN 6100-6-3:2007 EN 6100-3-1:2007(IEC 6100-4-2:2008 IEC 61000-4-3:2008)
Application
1)On Grid System,Off Grid System,Hybrid Sytem.
2)Solar lighting ,lamps,household electricity,highway transportation.
3)Construction and photovoltaic power planta and so on.
The electrical Characteristics of 260,270,280,290,300 watts solar panel
| Maximum Power at ST(Pmax)W | 260Wp | 270Wp | 280Wp | 290Wp | 300Wp |
| Maximum Power Voltage(Vmp)V | 36/18 | 36/18 | 36/18 | 36/18 | 36/18 |
| Maximum Power Current(Imp)A | 7.2/14.4 | 7.5/15 | 7.77/15.55 | 8.05/16.11 | 8.33/16.66 |
| Open Circuit Voltage(Voc)V | 39.15/19.1 | 39.2/19.3 | 39.3/19.4 | 39.3/19.4 | 39.6/19.8 |
| Short Circuit Current(Isc)A | 7.8/15.6 | 8.03/16.05 | 8.13/16.26 | 8.86/17.72 | 9.16/18.33 |
| Cell Efficiency(%) | 15.57% | 16.5% | 16.7% | 16.7% | 18.1% |
| Module Efficiency(%) | 14.8% | 15.4% | 15.9% | 16.5% | 17.2% |
| Operating Temperature º C | -40º Cto+85º C | ||||
| Maximum system voltage | 1000V(IEC)DC | ||||
| Power tolerance | +/-3% | ||||
| Temperature coefficients of Pmax | -0.45%/º C | ||||
| Temperature coefficiency of Voc | -0.27%/º C | ||||
| Temperature coefficiency of Isc | 0.05%/º C | ||||
| Weight(kg) | 25.5 | ||||
| Number of cell(pcs) | 6*12 | ||||
| Dimensions(mm) | 1920*1000*40 | ||||
Why choose our solar panel is you ideal choose?
1. The important raw material, Solar cells, come from domestic public company and Taiwan famous company. Quality assurance: 25 years long life span, Industry leading power output warranty 10 years 100%, 20 years 95%, 25 years 85%.
There are some company which select inferior solar cells that are processed from recycled silicon material from small workshop, so their solar panel service life maybe less than 5 years because inferior solar cell power reduce much more every year.
2. Our company has automated production line for solar panel. Good technology, good quality assurance. Strong production ability: 300 pieces 300w solar panels can be manufactured per day. Most of company weld solar cell with artificial manual work. Bad manufacturing technique is difficult to keep consistency of products.
