255W Poly Solar Panel PV Module with High Quality and Lower Price of PV Solar Panel
Description of PV
Pv solar module:
Scope: 40w - 310w/piece;
Solar cell: High efficient mono/poly crystalline silicon solar cell;
Long lifetime: More than 25years working life;
Tempered glass: High transmission rate glass increase the power output and mechanical strength of Solar module;
Frame: Aluminium alloy, without screw, corner connection;
Junction box: Multi function junction box with by pass diodes and wate proof;
Preventing from bad weather condition such as wind and hails;
Resisting moisture and erosion effectively, not effected by environment;
Certificate: ISO, CE,ROHS,TUV,IEC,CEC,CGC,UL,ETL,MCS,PV CYCLE,3E.Scope: 40w - 310w/piece;
Solar cell: High efficient mono/poly crystalline silicon solar cell;
Long lifetime: More than 25years working life;
Tempered glass: High transmission rate glass increase the power output and mechanical strength of Solar module;
Frame: Aluminium alloy, without screw, corner connection;
Junction box: Multi function junction box with by pass diodes and wate proof;
Preventing from bad weather condition such as wind and hails;
Resisting moisture and erosion effectively, not effected by environment;
Certificate: ISO, CE,ROHS,TUV,IEC,CEC,CGC,UL,ETL,MCS,PV CYCLE,3
Technology with PV
ITEM NO.: | Poly 156*156 cell ,60pcs . Power range from 230Wp-260Wp | ||||||
Maximum Power(W) | 230 | 235 | 240 | 245 | 250 | 255 | 260 |
Optimum Power Voltage(Vmp) | 29.4 | 29.5 | 29.7 | 30.1 | 30.3 | 30.5 | 30.7 |
Optimum Operatige Current(Imp) | 7.83 | 7.97 | 8.08 | 8.14 | 8.25 | 8.37 | 8.48 |
Open Circuit Voltage(Voc) | 36.7 | 36.8 | 36.9 | 37.1 | 37.3 | 37.5 | 37.7 |
Short Circuit Current(Isc) | 8.52 | 8.59 | 8.62 | 8.65 | 8.69 | 8.73 | 8.78 |
Solar Cell: | 156*156 Poly | ||||||
Number of Cell(pcs) | 6*10 | ||||||
Brand Name of Solar Cells | CNBM | ||||||
Size of Module(mm) | 1650*992*40/45/50 | ||||||
Cable & Connector Type | Pass the TUV Certificate | ||||||
Frame(Material Corners,etc.) | Aluminium-alloy | ||||||
Back sheet | TPT | ||||||
Weight Per Piece(KG) | 19.5KG | ||||||
FF (%) | 70-76% | ||||||
Junction Box Type | Pass the TUV Certificate | ||||||
Tolerance Wattage(e.g.+/-5%) | ±3%, or 0-3% | ||||||
Front Glass Thickness(mm) | 3.2 | ||||||
Temperature Coefficients of Isc(%) | +0.04 | ||||||
Temperature Coefficients of Voc(%) | -0.38 | ||||||
Temperature Coefficients of Pm(%) | -0.47 | ||||||
Temperature Coefficients of Im(%) | +0.04 | ||||||
Temperature Coefficients of Vm(%) | -0.38 | ||||||
Temperature Range | -40°C to +85°C | ||||||
Surface Maximum Load Capacity | 5400Pa | ||||||
Allowable Hail Load | 23m/s ,7.53g | ||||||
Bypass Diode Rating(A) | 12 | ||||||
Warranty | 90% of 10 years, 80% of 25 years. | ||||||
Standard Test Conditions | AM1.5 1000W/ 25 +/-2°C | ||||||
Packing | carton or pallet | ||||||
1*20' | 14 Pallets / 316pcs | ||||||
1*40'STD | 25 Pallets / 700pcs | ||||||
Production with PV
Solar panel quality and warranty
1. Peak power of single module in guaranteed in +-3%power tolerance.
2. Average power of modules in single order is guaranteed not less than the peak power
3. Rigorous quality control meets the highest international standard
5.5 years limited warranty on material and workmanship
6.10 years and 20 years limited warranty for minimum power output.
Aboutus with PV
CNBM International Corporation, as an important external business platform of CNBM Group, plays as a role to export solar products produced by CNBM. Headquartered in Beijing, We have entered into Solar PV industry since 2005. CNBM Solar is specialized in PV power systems which takes advantage of reliable supplying, convenient installation and free maintenance, and has been used widely, and it is the compensation and substitution of normal power supply. We provide power solutions for home, business and industrial customers, and provide off-grid PV systems for rural area. Our company not only can supply high quality solar Products, but also provides professional system Solutions and high quality services.
Question&Answer
How to buy your ideal products?
A: Providing the information of your projects required, then we will make the most suitable solution and products.
How to pay?
A:TT will be more appreciated. 30% deposit after oder confirmed, 70% before shipment.
What is the delivery time?
A: It depends on order quantities. Generally, the delivery time will be within 15 to 30 days.
How to pack the products?
A: We use standard package, carton boxes, wooded pallet. If you have special
package requirements, we will pack as required. The fees are negotiable.
How to install after the goods arriving destination?
A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
