Loading Port:Shanghai
Payment Terms:TT or LC
Min Order Qty:-
Supply Capability:3000pcs watt/month
Poly Solar Panels with TUV Certification
Mechanical Characterristics
I.Solar Cell : High efficiency crystalline solar cell. Even if under the weak light, the solar module can produce maximum power output.
II.Tempered glass (toughened glass): Anti-reflecting coating and high transmission rate glass increase the power output and mechanical strength of solar module.
III.EVA and TPT: Using high quality EVA and TPT to prevent destroying and water.
IV.AI frame: Without screw, corner connection. 6 holes on the frame can be installed easily.
V.Junction box: Multi function junction box with water proof.
VI.Good performance of preventing from atrocious weather such as wind and hails.
VII.Resisting moisture and etching effectively, not effected by geology.
Specifications
Module Type | 220P | 225P | 230P | 235P | 240P | 245P | 250P |
Maximum Power at STC (Pmax) | 220Wp | 225Wp | 230Wp | 235Wp | 240Wp | 245Wp | 250Wp |
Maximum Power Voltage (Vmp) | 30.00V | 30.10V | 30.20V | 30.30V | 30.40V | 30.55V | 30.65V |
Maximum Power Current (Imp) | 7.34A | 7.48A | 7.62A | 7.76A | 7.90A | 8.02A | 8.17A |
Open-circuit Voltage (Voc) | 36.00V | 36.70V | 36.80V | 37.26V | 37.32V | 37.44V | 37.80V |
Short-circuit Current (Isc) | 7.84A | 7.99A | 8.15A | 8.30A | 8.44A | 8.58A | 8.74 A |
Cell Efficiency (%) | 15% | 15.4% | 15.7% | 16% | 16.4% | 16.7% | 17.1% |
Module Efficiency (%) | 13.4% | 13.7% | 14% | 14.3% | 14.6% | 14.9% | 15.3% |
Operating Temperature( °C ) | -40°C ~+90°C | ||||||
Maximum System Voltage(V) | DC 1000V(TUV) / DC600V(UL) | ||||||
Maximum Rated Current Series(A) | 15A | ||||||
Power Tolerance | 0~+3% | ||||||
Temperature Coefficients of Pmax | (-0.45±0.05)%/°C | ||||||
Temperature Coefficients of Voc | (0.05±0.01) %/°C | ||||||
Temperature Coefficients of Isc | (-0.35±0.02)%/°C | ||||||
NOTC(°C ) | (47±2)°C | ||||||
STC: Irradiance 1000W/M2 Module Temperature: 25°C AM=1.5
Warranty
1. 10 years limited product warranty
2. 10 years at 90% of the minimal rated power output and 25 years at 80% of the minimal rated power output
Packing Configuration
Q’ty/Pallet, | 1×20’ft | 1×40’GP | 1×40’HQ |
Pallet Q’ty | 6pallets | 14pallets | 14pallets |
Q’ty/Container | 240pcs | 560pcs | 630pcs |
Package
FAQ
I. Will you focus on the safety of the goods during transportation?
Yes, Safety of the cargo is the primary element that we would consider on transportation.
II..How would guarantee the quality will meet the requirements of your clients?
Before shipment, we will have inspection for each batch of goods.
III..What certificates do you have?
IEC,UL,TUV,CSA,etc.
IV..Can you do OEM according to clients’ requirements?
Yes, we have our own brand while we can provide OEM service.
