Loading Port:China main port
Payment Terms:TT OR LC
Min Order Qty:50 watt
Supply Capability:10000 watt/month
Efficiency
1. Low voltage-temperature coefficient allows higher power output at high-temperature condition.
2. High efficient, high reliable solar cells ensure our product output stability.
Benefits
1. Manufactured in an ISO9001:2008 certified plant
2. High efficiency, high safety, high reliability
3. Output power tolerance of +/-3%
| STC | BSM240P-60 | ||||||
| Maximum Power | 240W | ||||||
| Module Efficiency | 14.66% | ||||||
| Maxi Power Current | 7.895A | ||||||
| Maxi Power Voltage | 30.4V | ||||||
| Short Circuit Current | 8.718A | ||||||
| Open Circuit Voltage | 37.2V | ||||||
| Power Tolerance | 0~+5W | ||||||
| Values at Standard Test Conditions STC(Air Mass AM1.5,Irradiance 1000W/m²,Cell Temperature 25℃) | |||||||
| Mechanical Characteristics | |||||||
| Cell Type | Polycrystalline 156x156mm,60(6x10)pcs in series | ||||||
| Glass | High Transmission,Low Iron,Tempered Glass | ||||||
| Frame | Anodized Aluminium Alloy | ||||||
| Junction box | IP65/IP67 rated,with bypass diodes | ||||||
| Dimension | 1640x990x35/40mm | ||||||
| Output Cable | 4mm2(EU)/12AWG(US),1000mm² | ||||||
| Weight | 19Kg | ||||||
| Installation Hole Location | See Drawing Above | ||||||
