Poway Solar Panels:240W Poly Solar Panel with High Efficiency Made in China

Product Description:

Product Description

240W Poly Crystalline Solar Panel

Product Highlights:
  1. Guarantee positive power tolerance (0~+3%)
  2. Module can bear snow loads up to 5400Pa and wind loads up to 2400pa
  3. High performance under low light conditions (cloudy days, mornings and evenings)
  4. Certified by Europe standards of TUV, IEC, CE and British MCS and AUS CEC
  5. OEM/ODM available


Specs

Electrical Characteristics
Maximum Power [Pmax]	240W
Power Tolerance	+/-3%
Maximum Power Voltage [Vmp]	29.8V
Maximum Power Current [Imp]	8.06A
Short-Circuit Current [Isc]	8.62A
Open-Circuit Voltage [Voc]	37.0V
Module Efficiency	14.75%
Max. System Voltage	1000VDC
Cell Size and Series	Poly 156*156  60pcs (6*10)
Temperature Coefficient of Pmax	- 0.47% / º C
Temperature Coefficient of Voc	- 0.33% / º C
Temperature Coefficient of Isc	0.05% / º C
Mechanical Characteristics
Dimension (mm)	1640*992*40
Frame	Anodized Aluminium Alloy
Glass	3.2mm,High Transmission,Tempered Glass
Junction box & Cable	IP65 Rated weatherproof connectors Cable: TUV 1x4.0mm2 / UL12AWG,Length:900mm
Weight	19.0Kgs

Industry-leading Warranty:
Warranty on material and workmanship: 10 years
Guaranteed output of 90% after 12 years and 80% after 25 years.
