Loading Port:Guangzhou
Payment Terms:T/T
Min Order Qty:100 Rolls roll
Supply Capability:100000 Rolls Per Month roll/month
Specification
| Model NO. | SMD5050 |
| Power Consumption | 7.2W/M |
| Work Voltage | DC12V/24V |
| Work Current | 0.6A/0.3A |
| Beam Angle | 120°-180° |
| LED Encapsulation | SMD 5050 |
| LED Quantity | 30LEDS/M |
| Color | Single Color(White,Warm White,Cold White,Red ,Green,Blue,Yellow,Pink),RGB |
| FPC Color | Yellow or White |
| FPC Dimension | 50*10*0.2mm |
| Waterproof Grade | IP33 IP67 IP68 |
| Work Temperature | -25-60deg |
| Light Decay | Less Than 3% After 3,000H |
| Life-span | 50,000H |
| Certificate | CE&ROHS |
| Every Roll | 5m |
| Warranty | 2 years |
| Luminous Flux | 540-650Lm/M (White:2700-12000K) |
| 500-610Lm/M (Red:620-630nm) | |
| 820-920Lm/M (Green:510-525nm) | |
| 200-280Lm/M (Blue:455-470nm) | |
| 260-330Lm/M (Yellow:585-595nm) | |
| LED Spacing | 33mm |
| Min.Cutting Unit | 3LEDS |
| Min.Cutting Length | 10mm |
| Max.Connecting In Series | 5M ,Or More Than 5M,Please Connect Them In Parallel |
| Application | Path&contour marking |
| Indoor and outdoor sign | |
| Adverisement led backlight | |
| Architectrual decorative lighting | |
| Stairway accent lighting | |
| Channel letter lighting | |
| Message sign lighting |
Features
1. Sealed to IP30.Humidity/Moisture resistant for indoor use
2. 50,000 hours life
3. High Flexibility.
4. Very Low Energy Consumption
5. Safe, Low Voltage Operation.
6. High visual impact
7. No RF interference
8. No UV light to avoid insects around
9. Maintenance free ,With 3M adhesive tape backside,easy to install
10. Solid with high stock resistance
11. 3 Leds cuttable with the mark and easy connecting with the snap-in connector and can be cut off at regular segments without damaging the rest ribbon.
12. Working with normal power supply and controller.
13. Available in many colors such white ,warm white ,cold white ,red ,green ,blue ,pink ,RGB and magic color etc.
Advantages
1. Lifespan more than 50,000hrs
2. CE&ROHS approved
3. Waterproof IP33 /IP67
4. High visual impact and excellent brightness
5. Cuttable at every 3 led,easily connection
6. Energy efficient,major reductong in power costs
Applications
1.Commercial and Residential
2.Archways
3.LED Cove Lighting
4.Canopy ,bridge edge lighting
5.Decorative LED lights for events
6.Display Cases
7.Home Theatre
8.Kiosks
9.LED Home Lighting
10.Outside Area
11.Paths & Contour
12.Hostess Stations
13.Edge lighting booths
14.Windows
