Loading Port:Shenzhen
Payment Terms:L/C,T/T
Min Order Qty:1000 Pcs pc
Supply Capability:100000 Pcs Per Month pc/month
Features:
1.Long lifespan: Use silica gel packages, effectively improve the heat dissipation performanc, can be used than 50,000hrs.
2.High energy efficiency:save 80% power than sodium lamps.
3.Environmental friendly: no lead,no mercury and no pollution.
4.More safety:good impact resistance, no UV rays, no IR rays.
5.Quick response: achieves high lumens within in nanoseconds.
6.No flicker, no strobe for less visual fatigue.
Notes:
1. All dimensions are in millimeters.
2. Tolerance is ±0.25mm unless otherwise specified.
3. Lead spacing is measured where the leads emerge form
4. Specifications are subject to change without noticed.the package.
Absolute maximum ratings (Ta=25°C)
Parameter | Symbol | Value | Unit |
Power dissipation | Pd | 1700 | mW |
Forward current | If | 500 | mA |
Reverse voltage | Vr | 5 | V |
Operating temperature range | Top | -40 ~+100 | °C |
Storage temperature range | Tstg | -40~+100 | °C |
Pulse Forward Current | Ifp | 700 | mA |
Electrostatic Discharge | ESD | 2000(HBM) | V |
Junction temperature | Tj | 105 | °C |
Electrical and optical characteristics(Ta=25°C)
Parameter | Test Condition | Symbol | Value | Unit | ||
Min | Typ | Max | ||||
Forward voltage | If=350mA | VF | 2.8 | 3.5 | V | |
Luminous intensity | If=350mA | Φ | 90 | 110 | Lm | |
Viewing angle at 50% Iv | If=350mA | 2 θ 1/2 | 120 | Deg | ||
Reverse current | Vr=5V | Ir | 10 | μA |
Package:1000pcs/reel
Application:
1. Lightings
2. Miner's lamp
3. Optical indicator
4. Signal & symbol luminaire.
5. Substitution of Micro incandescent lamps
6. Indoor & outdoor displays
7. Backlightings (LCD, cellular phone, switches, keys, displays, advertising)
Our advantages:
1.16 years experience in manufacturing, Encapsulation Center for LED in Xiamen
2.LED components supplier for LG,TPV,Lite-on, Mitsubishi
3.Well-trained and experienced staffs to help you slove your problem
4. A experienced R&D team to help design new products
5. Strict QC system for high quality
6. Guaranteed delivery time
Delivery:
Shipping Service | Estimated Delivery Time |
DHL | 2-8 business days |
FedEx | 3-8 business days |
TNT | 2-10 business days |
UPS | 1-7 business days |
EMS | 6-14 business days |
ePacket | 7-12 business days |
China Post Air Mail | 7-15 business days |
China Post SAL | 14-30 business days |
By Sea | 30-40 business days |
1. 3-5 business days for Sample Orders; 7-15 business days for Bulk Orders for Bulk Orders.
2. "Business days" means Monday-Friday, excluding holidays.
3. DHL and UPS cannot ship to military or P.O. boxes address
4. The Shipping Service above is for reference only, for any other questions, please feel free to contact us.
