Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
| Model | PTS180 | |
| Max.working height | 18M | |
| Max.platform height | 16M | |
| Loading capacity | 200kgs | |
| Lateral Outreach | 7M | |
| Platform rotation | – | |
| Jib rotation | 100° | |
| Turntable rotation | 350° | |
| Size of platform | 0.9×0.8×1.1M | |
| Overall stowed length | 5.95M | |
| Overall stowed width | 1.62M | |
| Overall stowed height | 2.4M | |
| Length outrigger footprint standard | ||
| Width outrigger footprint standard | ||
| Total weight | 1950KGS | |
| Traveling speed | 35km/h | |
| Power capacity | ||
| 1. standard power source | Diesel engine | |
| 2. optional power sources | 1.Electric 220V AC power | |
| 2.Battery | ||
| Specifications | ||
| ►Industry leading working envelope | ||
| ►Articulating boom | ||
| ►Multiple job site application,indoors and outdoors | ||
| ►high and low operation panel | ||
| ►Hydraulic outriggers and outrigger interlocks | ||
| ►Hydraulic surge brakes | ||
| ►350°non-continuous turntable rotation | ||
| ►All pipelines put inside the machine, to aviod tangled sun and rain or other objects | ||
| ►Made of high strength steel,famous china brand | ||
| ►Protective covers for oil-tank, emergency controls and etc. | ||
| ►Easy handling | ||
