Irosa Solar Panels - 160Wp Maximum Power High Efficiency Solar Panel

Product Description:

Product Description

• Maximum power: 60Wp

• Maximum power voltage: 18.00V

• Maximum power current: 3.33A

• Open circuit voltage: 21.60V

• Short circuit current: 3.60A

• Number of cells: 36 pieces (4 x 9)

• Cell dimensions: 78 x 156mm

• Module dimensions: 766 x 680 x 30mm

• Maximum system voltage: 1,000V

• Temperature coefficients of Isc: + 0.1%/°C

• Temperature coefficients of Voc: -0.38%/°C

• Temperature coefficients of Pm: -0.47%/°C

• Temperature coefficients of Im: +0.1%/°C

• Temperature coefficients of Vm: -0.38%/°C

• Temperature range: -40 to +85C

• Weight per piece: 7kg


• Junction box type: PV-JB001 (TUV)

• Connectors and cables with TUV certificate

• Length of cables: 900mm

• Output tolerance: ±3%

• Frame (material, corners and more): aluminum

• Standard test conditions: 1,000W/m², AM1.5 25'C

• Warranty: 10 years product warranty and 25 years 80% ofpower

• FF: e 70%

• Loading quantity:

• 20-foot container: 500 pcs

• 40-foot HQ container: 1,000 pcs
