Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:1000 watt
Supply Capability:10000000 watt/month
Product Details
Primary Competitive Advantages:
Product Features
Product Performance
Prompt Delivery
Quality Approvals
Reputation
Service
Small Orders Accepted
Rechargeable Fan
| ELECTRICAL CHARACTERISTICS | ||||||
| Maximum Power as per STC | Pmax(W) | 130 | 135 | 140 | 145 | 150 |
| Power Tolerance | % | ± 5% | ||||
| Maximum Power Voltage | Vm(V) | 17.96 | 18.14 | 18.36 | 18.15 | 18.28 |
| Maximum Power Current | Im(A) | 7.26 | 7.45 | 7.65 | 7.99 | 8.21 |
| Open Circuit Voltage | Voc(V) | 21.6 | 21.74 | 21.96 | 21.72 | 21.9 |
| Short Circuit Current | Isc(A) | 7.83 | 8.04 | 8.17 | 8.69 | 8.93 |
| Maximum System Voltage | VDC | 1000 | ||||
| Cell Efficiency | % | 15.0 | 15.5 | 16.1 | 16.7 | 17.3 |
| Module Efficiency | % | 12.9 | 13.4 | 13.9 | 14.4 | 14.9 |
| Cells per Module | Pcs | 36 | ||||
| Cell Size | mm | 156 x 156 | ||||
| Bypass Diodes | Pcs | 10Amp, 2 pcs | ||||
| Max. Series Fuse Rating | A | 10A | ||||
| Temperature coefficient of Isc | %/ | 0.05 | ||||
| %/ | -0.35 | |||||
| %/ | -0.47 | |||||
| NOCT- Nominal operating cell temperature | 47 ± 2 degree | |||||
| Operating Temperature | from -40 to +85 degree | |||||
| MECHANICAL CHARACTERISTICS | ||||||
| Dimensions | mm | 1480 x 680 x 35 | ||||
| Weight | Kg | 11.6 | ||||
| Type of Junction Box | TUV certified, IP65 | |||||
| Cable Type, Diameter | - | |||||
| Connector | - | |||||
| Tempered Glass | 3.2 mm, high transmission, low iron | |||||
