Loading Port:Shenzhen
Payment Terms:L/C,T/T
Min Order Qty:10 Pcs pc
Supply Capability:10000 Pcs per Month pc/month
12W led garden light IP66
Features
- Patent pending design.
- Easy installation way thanks to intergrated external high voltage driver with monochro matic model.
- RGB model compatible with DMX protocol.
- Uniquely designed rim on housing focusing light beam.
- Aluminum baking varnish finish with housing and oxidized frame.
Electrical Specification
-LEDType : Edison 3W
-LED Quanty:6 LED
-Housing :Aluminum + tempered glass
-Operating Temperature:—20°C°C ~50
-Production Dimensions:140*104*492mm
-Underground Height: 265mm
Specifications
| Model Number | Color | LED Type | LED Q ’ty | Light Output (lumen/m) | BeamAngle (degrees) | CRI | Protection against electric shock | Waterproof | Power | PF | Voltage | Max.Current (Amps) |
| HL-012-AW-W-01 | W | Edison 3W | 6 | 752 | 15°/25° | 78 | level I | Ip66 | 12W | ≥0.9 | AC100-240V | 0.15 |
| HL-012-AW-WW-01 | WW | 725 | 15°/25° | 56 | level I | Ip66 | ≥0.9 | AC100-240V | 0.15 | |||
| HL-012-AW-NW-01 | NW | 728 | 15°/25° | 63 | level I | Ip66 | 1.0 | AC100-240V | 0.15 | |||
| HL-012-D4-W-01 | W | 792 | 15°/25° | 78 | level III | Ip67 | 1.0 | DC 12-24V | 1.2 | |||
| HL-012-D4-WW-01 | WW | 759 | 15°/25° | 55 | level III | Ip67 | 1.0 | DC 12-24V | 1.2 | |||
| HL-012-D4-NW-01 | NW | 772 | 15°/25° | 64 | level III | Ip67 | 1.0 | DC 12-24V | 1.2 |
Our unique services:
1. For all your inquires about us , well-trained sales reply to you in detail within 24 hours
2. We offer OEM services due to your request
3. We have cooperate with FuDan university institution,and we have strong ability to do ODM projects
4.We have exported led highbay,led panel,led flood lights for 7 years ,cooperate with Honeywell,Marley and so on
Delivery:
Shipping Service | Estimated Delivery Time |
DHL | 2-8 business days |
FedEx | 3-8 business days |
TNT | 2-10 business days |
UPS | 1-7 business days |
EMS | 6-14 business days |
ePacket | 7-12 business days |
China Post Air Mail | 7-15 business days |
China Post SAL | 14-30 business days |
By Sea | 30-40 business days |
1. 3-5 business days for Sample Orders; 7-15 business days for Bulk Orders for Bulk Orders.
2. "Business days" means Monday-Friday, excluding holidays.
3. DHL and UPS cannot ship to military or P.O. boxes address
4. The Shipping Service above is for reference only, for any other questions, please feel free to contact us.
