Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1000 pc
Supply Capability:100000 pc/month
Features:
1. Using high power Bridgelux LED chip, lumen efficiency of the whole lamp could reach 100-110lm/w
2. Adopt waterproof Mean Well driver or high quality CN driver,power factor>0.95
3. Passed CE, RoHS.
4. With fashion design and elegant appearance.
5.Modules design,30w/module,single module can be adjustable .
6.Various beam angle of lens to choose.
120W LED Tunnel Light Specification:
Power consumption | 120W |
Input voltage | AC 100-240V / 50-60Hz |
LED QTY | 120PCS |
Light source | USA Bridgelux |
Total harmonic distortion | ≤9% |
Driver | Mean Well |
Power factor | >0.95 |
LED efficiency | 115-125Lm/W |
LED light luminous efficiency | 100Lm/W |
Color temperature | Warm White: 2700-3500K |
Pure White: 4000-4500K | |
Cool White: 5500-6000K | |
CRI(Ra) | >60 |
IP grade | IP65 |
LED junction temperature | ≤70°C |
Ambient temperature | -40°C—45°C |
Material | Aluminum |
Lifespan | 50,000hrs |
Warranty | 3 years |
Certification | CE/RoHS |
LED Tunnel Light Color Temperature Available :
Warm White:2700-3500K
Pure White:4000-4500K
Cool White:6000-6500K
Other Color temperature also can be customized according to your demands .
LED Tunnel Light Application and Quality control :
| Applications: | Apply to all kinds of tunnels, such as highway tunnel, arterial traffic tunnel, collector street tunnel, pedestrian tunnel and underground passage. |
| Quality: | pass CE, ROHS, LVD, EMC Certificates |
| 100% test before sending out. | |
| Quality assure 3 years. |
