Loading Port:Qingdao
Payment Terms:TT OR LC
Min Order Qty:1 m.t.
Supply Capability:1000000 m.t./month
Characteristics
*Low density, low thermal conductivity
*Excellent thermal resistance to shock
*Resistance to air eroding
*Excellent mechanical strength
*Good safety with anchor inside
*Easy to install
Typical Application
*Ceramics:shuttle kilns,tunnel kilns,kiln car etc
*Steel:heater,continuous annealing furnace,galvanizing line,kiln car etc
*Heat treating:annealing furnace,normalizing furnace,kiln car etc
* Petrol-chemical:cracking heater,reformer,gas flue etc
Physical & Chemical Data
Description | 1260 NATI Ceramic Fiber Module | 1425 NATI Ceramic Fiber Module | 1500 NATI Ceramic Fiber Module | 1600 NATI Ceramic Fiber Module |
Classification temperature( ℃) | 1260 | 1425 | 1500 | 1600 |
Density( Kg/m3 ) | 130~192 | |||
Lineal shrinkage( % ) | ( 1100℃ x 24 hrs ) 1.0 | ( 1200℃ x 24 hrs) 1.1 | ( 1300℃ x 24 hrs ) 1.2 | ( 1400℃ x 24 hrs ) 1.1 |
Average 400℃ | 0.09 | |||
Average 600℃ | 0.14 | 0.12 | 0.11 | 0.1 |
Average 800℃ | 0.2 | 0.18 | 0.16 | 0.15 |
Average 1000℃ | 0.21 | 0.19 | 0.18 | |
Standard Dimension:
305*305*305mm
FAQ
Q3: What other products does OKorder offer?
A3: We offer a full range of refractory bricks, monolithic material, ceramic fiber products, and more.
Q4: If I need your offer, what information do you need?
A4: In order to choose suitable products, it will be appreciated to provide us the information, such us specification, technical data, order quantity, products application etc.
If any question, please contact us freely.
