Loading Port:China main port
Payment Terms:TT OR LC
Min Order Qty:1 unit
Supply Capability:50 unit/month
Efficient power generation, higher returns
9-12 MPPT, single tracking accuracy is high, dynamic response speed is fast, higher power generation
1.5x DC supermatch
Maximum efficiency %, wide voltage range (180-1000V), early start and late stop, more durable power generation
Suitable for high current components
Intelligent protection operation and maintenance is simple
Intelligent IV diagnosis can accurately locate string faults and proactively find problems
Support fault recording, real-time observation and recording of inverter AC voltage and current waveform, quickly locate problems
Support RS485 (WiFi/DRM/ Bluetooth optional), mobile phone/computer intelligent monitoring, anytime and anywhere more convenient operation
Safe and reliable, comprehensive Warranty
IP66 high protection, support outdoor installation
AC-DC secondary lightning protection, actively eliminate lightning hazards
DC arc detection (AFCI) function is optional, accurately distinguish arc signal, fast shutdown, avoid fire
IEC/EN 62109-1/2, IEC/EN 61000-6-1/3, IEC/EN 61000-6-2/4, EN50549, IEC61727/IEC62116, CEI 0-21/CEI 0-16, C10/C11, VDE 4105, VDE 0124, G99, RD244, UNE217001, UNE217002, NC RfG, TOR Erzeuger, NRS097-2-1, NB/T 32004
Night power consumption <1W
Size:1050 x 660 x 330 mm
Weight:95/98/101kg(100KW/110KW/136KW)
Quality Warranty:5-10 years
