Loading Port:Shanghai
Payment Terms:TT or LC
Min Order Qty:5 m²
Supply Capability:9000 m²/month
Product Description
0.4mm alloy aluminum sheets 3003 H14
Alloy:3003
Temper: O H H12 H14 H18 H24
Thickness(mm):0.2-350mm
Width(mm):200-2300
Length(mm):800-13000
Delivery lead time: 20-25 days
Packing: wooden/veneer pallet, wooden/veneer case
Unit Price/Payment: FOB, CIF, CFR
Payment term: TT, LC at sight, Westen union
Country of origin: China
Certificate approved: ISO9001, SGS
MOQ: 2.0-2.5 metric ton per size
3003 Chemistry Composition | |||||||||
Element | Si | Fe | Cu | Mn | Mg | Cr | Ti | Zn | Al |
Standard Value | 0.6 | 0.7 | 0.05~0.20 | 1.0~ 1.5 | --- | --- | ---- | 0.10 | remainder |
3003 Aluminum is alloyed with 1.20% manganese, which increases the strength of 3003 over commercially pure aluminum (1100 series). 3003 has excellent workability, weldability, and good corrosion resistance. It is used for drawing, forming, spinning, fuel tanks, sheet metal works and other applications that require moderate strength for an aluminum with good weldability. H14 designates the temper, and means that 3003 has been strain hardened and partially annealed. In this condition, 3003 can be easily formed. Embossing or debossing 3003 in this temper should not strain or crack the plate.
The aluminum3003 ALUMINUM TREAD PLATE - Often referred to as diamond plate, it has the same properties of 3003H14, while excellent at resisting corrosion, and strong for light weight aluminum applications. The diamond trend pattern is slip-resistant and cosmetically appealing.
Applications:
· Cat Walks
· Heat Exchangers
· Food and Chemical handling equipment
· Truck and Trailer Roofing
· Floor Panels
| Packaging Details: | Export standard seaworthy fumigated wooden pallet only |
| Delivery Detail: | 15days |
