Loading Port:Ningbo
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:10000 m²/month
Plastic Formwork System - Column Formwork
The column panels are interconnected using the standard nylon locking handles. Each panel will require 9 handles. The forming face has 6 parallel rows of fixing holes to allow the orthogonal connection of the panels in a “star” shape. The rows are placed at a distance of 100/50mm the one from the other, allowing the forming of square and/or rectangular columns with side of 150 to 600mm.
light weight, high strength
The material of modular formwork is PP (polypropylene) mixed with special glass fibers which enable panels to hold high pressures.
The handles are made by high strength Nylon, each panel locked by at least 4 handles, which makes the whole system strong enough to pour 40cm walls.
product name | Modular formwork |
origin | China |
color | Black |
material | PP |
weight | 11kg |
tensile strength | 40KN |
reusable | 100 times |
Please send your project design drawing in Auto-CAD file to us, we will help to make formwork solution for you.
