Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
UT80-90 Strengthen Type 4WD Agricultural Tractor Specification
Model | UT804 | UT854 | UT904 | UT954 |
Drive type | 4x4 | 4x4 | 4x4 | 4x4 |
Overal size(LxWxH)mm | 4593 x2050 x2810 | |||
Wheel base(mm) | 2193.5 | 2193.5 | 2193.5 | 2193.5 |
Mininum ground clearance(mm) | 389 | 389 | 389 | 389 |
Front tire | 11.2-24 | |||
Rear tire | 16.9-34 | |||
Engine | ||||
Engine Model | LRC4108T77-1 | LR4B3Z-77-A | LR4MC-77-1 | LR4B3Z-T-85 |
Type of engine | Vertical,direct injection,water cooled, 4 cylinder,4 Stroke diesel engine | |||
Capacity of fuel tank(L) | 150L | 150L | 150L | 150L |
Engine power | 59KW | 62.5KW | 66.2KW | 70KW |
PTO power at rated speed | 2300 | 2400 | 2300 | 2300 |
Clutch | Dry,dual stage type | |||
PTO speed | 540/1000,( 760/1000 optional) | |||
Gear shift | 8F+4R /16F+8R(Optional)/8F+8R (Optional) | |||
Hydraulic output valve | Mulit-way Valve (optional) | |||
Category of 3-point link | II | II | II | II |
Lifting force(at point of 610mm)KN | 19.5 | 19.5 | 19.5 | 20.1 |
Speed (Km/h) | 2.31-34.85 | |||
