Loading Port:Tianjin
Payment Terms:TT or LC
Min Order Qty:1000 m²
Supply Capability:900000 m²/month
1. Description of HDPE Geomembrane
CMAX smooth geomembrane is made from high grade polyethylene raw material, adding carbon black, antioxidant, anti-aging and UV-resistance component. It adopted the first class automatic production equipment and three-layer pressing technology. All products are in accordance with GB, GRI and ASTM test standard.
2. Specification of HDPE Geomembrane
Thickness: 0.2mm – 3.0mm
Width: 2m – 12m
Color: Black, green, blue and white.
Material: HDPE, LDPE, LLDPE.
3. Technical Data Sheet of HDPE Geomembrane
Item | Unit | Test Method | Index | ||||||
Thickness | Mm | D5199 | 0.75 | 1.00 | 1.50 | 2.00 | 3.00 | ||
Density | g/cc | D1505/D792 | 0.94 | ||||||
Tensile Properties | Yield strength | KN/m |
Type IV | 11 | 15 | 22 | 29 | 44 | |
Break strength | KN/m | 20 | 27 | 40 | 53 | 80 | |||
Yield elongation | % | 12 | 12 | 12 | 12 | 12 | |||
Break elongation | % | 700 | 700 | 700 | 700 | 700 | |||
Tear Resistance | N | D1004 | 93 | 125 | 187 | 249 | 374 | ||
Puncture Resistance | N | D4833 | 240 | 320 | 480 | 640 | 960 | ||
Stress Crack Resistance | Hr. | D5397 | 300hr | ||||||
Carbon Black Content | % | D4218 | 2.0~3.0% | ||||||
Oxidative Induction Time | Standard OIT | Min | D3895 | 100min | |||||
High Pressure OIT | Min | D5885 | 400min | ||||||
Oven aging 85℃ retained after 90 days | Standard OIT | % | D3895 | 50% | |||||
High Pressure OIT | % | D5885 | 80% | ||||||
High Pressure OIT Retained after 1600hrs | % | D5885 | 50% | ||||||
4. Property of HDPE Geomembrane
1). Excellent environmental stress cracking resistance property.
2).Low temperature resistance, corrosion resistance, aging resistance.
3).For service temperature range: -60℃ - +60℃.
4).Service valid term: 60 years at least.
5. Application of HDPE Geomembrane
1). Municipal environmental projects, water conservancy projects.
2).Landfill cap, mining heap leach pads.
3).Pond liner, canal linings, tank linings, raw water treatment reservoirs, retention ponds.
4).Waste water treatment lagoon, secondary containment.
FAQ
Q: Can you accept sample order?
A: Yes, we are willing to send small samples for free, while the shipping fee should be afforded by yourself.
Q: What is your delivery time?
A: 1 days for samples, two weeks for mass production.
Q: What is your payment terms?
A: T/T , L/C, Western Union, Money Gram. 30% advance before producing, 70% payment before deliverying.
Q: How can I get my order?How can I know you sent the goods.
A: We will send you the goods by UPS, DHL, Fedex, Oversea Shipment or other forwarder,
all with tracking number or B/L.
Q:How about your quality?
A: Try a small order, you will have your own judgment!
