Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Forklift Truck EPA Approved 5ton LPG
Model NO.:CPQYD25
Type:Powered Pallet Truck
Power:Gasoline Engine
Load Capacity:1T - 5T
Fuel:Gas/Petrol
Load center:500mm, 500
Lift height:3000~5000mm
Condition:New
Size:2070*2502*1170
Place of Origin:Anhui, China (Mainland)
Brand Name:Vmax
Mast Lifting Height:3000mm
Certification:CE
Engine:Gq-4y
Export Markets:Global
Trademark:vmax
Packing:Nude Package
Standard:CE
Origin:Anhui, China
HS Code:8427209000
Production Capacity:5000sets /Year
2.5TON: STANDARD CONFIGUATION:
CPQYD25: Load capacity 2500kg, automatic transmission,
3m 2 stage duplex mast,
China gasoline engine GQ4Y, Electronic gear transmission,
1070mm fork,pneumatic tyres,safety seat.
FURTHER OPTION:
The following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m
Side shifter, Fork positioner, Longer forks, Fork extension
OTHERS:
A: Date of delivery: 15-25days after received the deposit
B: Payment terms: T/T(30% deposit, balance paid before shipment). Or L/C at sight
C: Guaranty period: One year or 2000hours upon receiving goods.
| Model | CPQYD25 | |||
| Load capacity | kg | 2500 | ||
| Load center | mm | 500 | ||
| Power type | Gasoline/LPG/CNG | |||
| Max. lifting speeds | mm/s | 400 | ||
| Max. Driving speeds | km/h | 17/19 | ||
| Max. Towing | KN | 15/10 | ||
| Grade ability | % | 15/20 | ||
| H1 Lifting height | mm | 3000 | ||
| Free lift | mm | 60 | ||
| Tilting angles | 6/12 | |||
| Min.turning radius | mm | 2450 | ||
| Min.right angle aisle width | mm | 2050 | ||
| Min.under-clearance | mm | 110 | ||
| Dimensions | A Overall length(including fork) | mm | 3605 | |
| B Overall width | mm | 1160 | ||
| H Overall height(mast lowered) | mm | 2095 | ||
| H2 Overall height(mast extend) | mm | 4080 | ||
| Tyre | Front tyre | 7.00-12 | ||
| Rear tyre | 6.00-9 | |||
| Total weight | kg | 3600 | ||
| Engine | Engine model | Chinese GQ-4Y/Nissan K21/K25 | ||
| Rate Power | kw | 37/36 | ||
| Rotate Speed At Rate power | ram | 2650/2400 | ||
| Max. torque | Nu | ≥148 | ||
| Rotate speed at max torque | ram | 1800-1900 | ||
