Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Diesel Forklift Truck 3 Ton with Isuzu Engine (CPCD30)
Model NO.:CPCD30
Type:3 Ton Diesel Forklift Truck
Power:Diesel Engine
Load Capacity:1T - 5T
Manufacturer:Anhui Heli Co., Ltd
Engine:Japanese Nissan, Isuzu Engine
Condition:New
Rated Loading Capacity:3000kg
Max. Lifiting Height:3000 Mm and Optional
Fork Size T*W*L:45*125*1070mm
Total Approximate Weight:3680kg-4700kg
Tyre Type:Pneumatic
Color:Yellow
After-Sales Service:Overseas Third-Party Support Available
Export Markets:Global
Trademark:HELI Second Brand: CHL
Packing:Export Standard Specification, 20gp for 3 Units
Standard:CQC CE
Origin:Anhui, China (Mainland)
HS Code:8427
Production Capacity:1000units
CHL is new brand of Anhui HELI Group, which is the best and largest forklift manufacturer in China, ranking No. 8 in the global forklift market in 2013.
CHL forklifts are positioned as Reliable Quality with More Competitive Price.
CHL forklifts share same production line and managing system with HELI brand forklifts, CHL is as the same quality as HELI forklifts.
CHL from HELI
55 years' professional manufacturing
Top 8 in the world market
The biggest forklift R&D base in China
The largest forklift Testing Center in China
CHL in HELI
3.0 ton Diesel Forklift
with Isuzu 4JG2 Engine
with Isuzu C240 Engine
with Chinese Engine
with HELI Hydraulic Transmission
Reliable Quality and More Competitive Price
| General | Manufacturer | Anhui Heli Co., Ltd | Anhui Heli Co., Ltd | Anhui Heli Co., Ltd | ||
| Model | CPCD25 | CPCD30 | CPCD35 | |||
| Power Type | Diesel | Diesel | Diesel | |||
| Rated Capacity | kg | 2500 | 3000 | 3500 | ||
| Load Center | mm | 500 | 500 | 500 | ||
| Size | Overall max.lifting height ( with backrest) | mm | 4030 | 4262 | 4262 | |
| Max.Lifting height | 3000 | 3000 | 3000 | |||
| Height mast retracted (upright) | mm | 2000 | 2065 | 2180 | ||
| Free lift height | mm | 170 | 160 | 170 | ||
| Backrest height (from upper face of forks) | mm | 995 | 1227 | 1222 | ||
| Overall height (overhead guard) | mm | 2170 | 2190 | 2190 | ||
| Overall length (without forks) | mm | 3646/2576 | 3752/2682 | 3763/2693 | ||
| Wheel base | mm | 1600 | 1700 | 1700 | ||
| Min.groud clearance under mast | mm | 110 | 135 | 135 | ||
| Overall width | mm | 1170 | 1225 | 1225 | ||
| Lateral fork adjustment (outside of fork) | mm | 1024/200 | 1060/250 | 1060/250 | ||
| Tread (front) | mm | 970/970 | 1000/970 | 1000/970 | ||
| Inside turning radius | mm | 2240 | 2400 | 2420 | ||
| Outside turning radius | mm | 160 | 200 | 200 | ||
| Min.intersecting aisle | mm | 2280 | 2380 | 2400 | ||
| Tilting angles (forward/backward) | 6°/12° | 6°/12° | 6°/12° | |||
| Fork Size | mm | 1070*122*40 | 1070*125*45 | 1070*125*50 | ||
| Service Mass | kg | 3680 | 4270 | 4700 | ||
| Performance | Max.Traveling speeds (laden/unladen) | km/h | 18/19 | 19/20 | 19/19 | |
| Lifting Speeds (laden/unladen) | mm/s | 506/545 | 465/490 | 370/400 | ||
| Lowering Speeds (laden/unladen) | mm/s | 450/550 | 450/550 | 350/370 | ||
| Max.Draw-bar pull (laden/unladen) | kN | 18.3/13.3 | 20/15.8 | 20/16 | ||
| Max.Negotiable Gradient (laden/unladen) | % | 20/20 | 15/20 | 20/20 | ||
| Tyre | Wheel (Front/Rear) X=Driving Wheel | 2X/2 | 2X/2 | 2X/2 | ||
| Tyre(Front/Rear) | Pneumatic type | Pneumatic type | Pneumatic type | |||
| Tyre size (Front) | 7.00-12-12PR | 28x9-15-12PR | 28x9-15-14PR | |||
| Tyre size (Rear) | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | |||
| Engine | Internal Combustion Engine Model | ISUZU C240PKJ | ISUZU 4JG2 | ISUZU 4JG2 | ||
| Internal Combustion Engine Rated Output | kw/rpm | 35.4/2500 | 44.9/2450 | 44.9/2450 | ||
| Internal Combustion Engine Rated Torque | Nm/rpm | 139/1800 | 186.3/1600~1800 | 186.3/1600~1800 | ||
| Internal Combustion Engine Fuel Tank Capacity | L | 60 | 60 | |||
FAQ:
1. Is the quality same with HELI brand forklifts?
Yes, CHL share the same production line with HELI brand forklifts.
Same factory, same components, same support team.
2. What's the difference between CHL and HELI?
CHL is with more modern design, new yellow color.
CHL has better price.
3. What's the warranty period?
15 months or 2000 working hours (which comes first).
4. How CHL do the after-sale service?
HELI Group has the best after-sale service system.
Depending on the advanced SAP system, all parts No. and parts information can be tracked immediately.
Over 20,000 kinds of main spare parts are in-stock.
All the warranty parts will be sent at the first time by TNT/DHL without charge and air freight.
5. Who is Shintool?
Shintool Machinery is the only company which has been officially authorized by HELI Group to look for CHL dealers and sell CHL forklifts.
We are sincerely looking for dealers for CHL forklifts globally.
Welcome your contact any time!
